Geratherm · Spirometers
Spirostik Blue
Spirostik Blue is a mobile Bluetooth spirometer from Geratherm Respiratory, used with the BLUE CHERRY Windows software. Its roll in handle lets the flow sensor be changed within seconds, so no separate mouthpieces or filters are needed. It can be run as a single user spirometer or as part of a networked SQL database installation.
- Sensor changed in seconds
- Blue Cherry SQL software
- GDT and HL7 interfaces
Installation, clinical application training and 24 months warranty are included on every supply.
Key features
- Wireless Bluetooth connection to the PC, no cable to the patient
- Roll in handle allows the flow sensor to be changed within seconds
- No additional mouthpieces or filters required
- Low flow resistance for patient comfort
- Automatic stand by and power up for long battery life
- BLUE CHERRY software with automatic diagnosis interpretation and WYSIWYG reports
- SQL database, networkable, with GDT and HL7 interfaces
- Optional Ambistik accessory for automatic BTPS correction in real time
Specifications
| Flow sensor principle | Differential pressure (Blueflow) |
|---|---|
| Range | ±16 L/s |
| Accuracy | ±3% or 50 mL/s, all ATS/ERS specifications |
| Dead space | Less than 50 mL effective |
| Resistance | Less than 0.07 kPa/(L/s) at flows below 14 L/s |
| Sampling rate | 125 Hz |
| Dimensions | 210 x 175 x 75 mm (L x W x H) |
| PC interface | Bluetooth 4.0 |
| Power supply | 2 x AA (HR6 / LR6) |
| Software | BLUE CHERRY, requires Windows 7 SP1 or newer |
| Test programs and procedures | Spirometry, flow volume, MVV; individual test, pre and post |
| Options | Bronchial provocation, breathing pattern analysis |
| Predicted sets | GLI 2012, ECCS 1993, NHANES III, Zapletal and others |
| Quality control and interpretation | Acceptability and repeatability to ATS/ERS 2005, semi automatic diagnosis |
Taken from the manufacturer documentation and subject to change without notice. Ask us for the current datasheet before you specify or tender.
Typical applications
- Routine spirometry
- Networked clinics
- Mobile testing
What is included
InstallationCommissioned on site by our engineers and calibration verified before handover.
TrainingClinical application training on the protocols your department will run.
Warranty24 months standard, extendable at the time of order.
ServiceAMC and CAMC contracts with preventive visits and spares held locally.
Frequently asked questions
What is included in the price of the Spirostik Blue?
On site installation and commissioning by our own engineers, clinical application training for your staff, and 24 months standard warranty. Consumables and accessories are quoted separately so you can see exactly what you are paying for.
How long does delivery take for the Spirostik Blue?
Stocked items usually reach you within seven working days of a confirmed order. Configured systems are built to order by the manufacturer, and we confirm the lead time in writing before you release the purchase order.
Can we see the Spirostik Blue demonstrated before we order?
Yes. We bring the equipment to your facility so the team can run it on a real workflow before committing. Ask for a demonstration on +91 98844 97422 and we will arrange a date.
Is service and AMC available for the Spirostik Blue?
Yes. Annual and comprehensive maintenance contracts are available with scheduled preventive visits, printed calibration records for your quality file, and priority response. Spares and consumables for this system are held locally.
